MPC8572E PowerQUICC III Integrated Processor Hardware Specifications, Rev. 4

Freescale Semiconductor

113

Package Description

SGND_SRDS1

SerDes Transceiver Core Logic

GND (xcorevss)

C28, C32, D30, E31,

F28, F29, G32, H28,

H30, J28, K29, L32,

M30, N31, P29, R32

——

—

SGND_SRDS2

SerDes Transceiver Core Logic

GND (xcorevss)

AE28, AE30, AF28,

AF32, AG28, AG30,

AH28, AJ28, AJ31,

AL32

——

—

AGND_SRDS1

SerDes PLL GND

J31

—

AGND_SRDS2

SerDes PLL GND

AH31

—

OVDD

General I/O Supply

U31, V24, V28, Y31,

AA27, AB25, AB29

—OVDD

—

LVDD

TSEC 1&2 I/O Supply

AC18, AC21, AG21,

AL27

—LVDD

—

TVDD

TSEC 3&4 I/O Supply

AC15, AE16, AH18

—

TVDD

—

GVDD

SSTL_1.8 DDR Supply

B2, B5, B8, B11, B14,

D4, D7, D10, D13, E2,

F6, F9, F12, G4, H2,

H8, H11, H14, J6, K4,

K10, K13, L2, L8, M6,

N4, N10, P2, P8, R6,

T4, T10, U2, U8, V6,

W4, W10, Y2, Y8, AA6,

AB4, AB10, AC2, AC8,

AD6, AD12, AE4,

AE10, AF2, AF8, AG6,

AG12, AH4, AH10,

AH16, AJ2, AJ8, AJ14,

AK6, AK12, AK18, AL4,

AL10, AL16, AM2

—GVDD

—

BVDD

Local Bus and GPIO Supply

A26, A30, B21, D16,

D21, F18, G20, H17,

J22, K15, K20

—

BVDD

—

Table 75. MPC8572E Pinout Listing (continued)
