1 / 5 page  17.08.2017 XSL-375-TF-R2 1 of 5 XSL-375-TF-R2 TECHNICAL DATA UV LED, TO46 with flat glass window Drawing Absolute Maximum Ratings (Ta=25°C) Item Symbol Value Unit DC Forward Current IF 25 mA Peak Pulse Forward Current * 1 IFP 100 mA Power Dissipation PD 100 mW Operating Temperature TOP -30 … +80 °C Storage Temperature TSTG -30 … +100 °C Soldering Temperature * 2 TSOL 260 °C * 1 pulse wi dth ≤ 0.1 ms, duty ratio ≤ 1/10 * 2 for 10 sec. Specifications (If=20mA, Ta=25°C) Item Symbol Min. Typ. Max. Unit Electrical Specification Forward Voltage * 1 UF 3.2 3.6 4.2 V Optical Specification Optical Power PO 4.0 - 6.0 mW Peak Wavelength * 2 λ P 375 - 380 nm Spectral Half Width (FWHM) λ - 12 - nm Viewing Angle φ 120 deg. * Note: 1. measurement tolerance is ± 0.2 V 2. measurement tolerance is ± 2 nm |
