AD8372

Data Sheet

Rev. C | Page 6 of 16

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage, VS

5.5 V

ENB1, ENB2, SDI1, SDI2, SDO1, SDO2, CLK1,

CLK2, LCH1, LCH2

DGDx − 0.5 V to

VS + 500 mV

Input Voltage, VIPC1, VINC1, VIPC2, VINC2

AGDx − 0.5 V to

VS + 500 mV

Internal Power Dissipation

1.4 W

θJA (Exposed Paddle Soldered Down)

34.6°C/W1, 2

θJC (At Exposed Paddle)

3.6°C/W2

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

1 Still air.

2 All values are modeled using a standard 4-layer JEDEC test board with the

pad soldered to the board and thermal vias in the board.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.
