Typical Performance Data

086-7SBSM+

INSERTION LOSS

0.0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0

3000

6000

9000

12000

15000

18000

FREQUENCY (MHz)

Frequency

(MHz)

Insertion Loss

(dB)

Return Loss

(dB)

SMA-Male

SMA-Female

Bulkhead

086-7SBSM+

RETURN LOSS

0

10

20

30

40

50

60

0

3000

6000

9000

12000

15000

18000

FREQUENCY (MHz)

SMA-MALE

SMA-Female

Bulkhead

50Ω

7 inch DC to 18 GHz

CASE STYLE: KP1567-7

086-7SBSM+

1. Custom sizes available, consult factory.

Outline Dimensions (

)

inch

mm

A

B

C1

C2

D

7.0

.51

.438

.232

.36

177.80

12.95

11.13

5.89

9.14

E1

E2

F

T

wt

.313

.250

.108

0.1

grams

7.95

6.35

2.75

2.54

9.20

Coaxial Cable

HAND

TM

Cable Construction

Outline Drawing

PANEL THICKNESS .100 INCHES

Maximum Ratings

Operating Temperature

-55°C to 105°C

Storage Temperature

-55°C to 105°C

Power Handling at 25°C, 211W at 0.5 GHz

Sea Level

150W at

1 GHz

101W at

2 GHz

59W at

6 GHz

45W at 10 GHz

35W at 18 GHz

Permanent damage may occur if any of these limits are exceeded.

100

0.04

46.4

46.8

1000

0.11

55.8

47.0

1800

0.16

42.3

40.7

2000

0.20

37.7

37.8

4000

0.26

35.6

36.0

5000

0.31

36.8

38.6

6000

0.36

34.7

34.3

7000

0.36

34.7

34.2

8000

0.36

34.7

34.2

9000

0.41

28.0

26.2

10000

0.41

28.0

26.2

12000

0.52

23.1

26.1

14000

0.61

22.5

23.7

17069

0.75

23.3

25.0

18000

0.70

23.7

23.8

Electrical Specifications at 25°C

Parameter

Condition (GHz)

Min.

Typ.

Max.

Unit

Frequency Range

DC

18

GHz

7

inches

Insertion Loss

DC - 2

—

0.14

0.4

dB

2 - 6

—

0.26

0.6

6 - 10

—

0.39

0.8

10 - 18

—

0.59

1.1

Return Loss

DC - 2

23

43

—

dB

2 - 6

23

38

—

6 - 10

17

30

—

10 - 18

16

25

—

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Features

• Wideband frequency coverage, DC to 18 GHz

• Low Loss, 0.7 dB at 18 GHz

• Excellent Return Loss, 24 dB at 18 GHz

• SMA-F bulkhead connector at one end

• Hand formable to almost any custom shape without

special bending tools

• 6mm bend radius for tight installations

• Anti-torque nut prevents cable stress during installation

• Insulated outer jacket standard

• Connector interface, meets MIL-STD-348

•

Ideal for interconnect of assembled systems

Applications

• Bulkhead connector mounts on front panel of equipment racks

• Replacement for custom bent 0.086" semi-rigid cables

• Communication receivers and transmitters

• Military and aerospace system

• Environmental and test chambers

Center Conductor: Silver Plated Copper Clad Steel

Dielectric: Solid PTFE

Outer Shield: Copper braid, tin soaked

Jacket: FEP, Blue (Unjacketed cable also available

upon request)

Connectors: Coupling Nut: Stainless Steel Passivated

Body: Stainless Steel Gold Plated

Center Pin: Brass, Gold Plated (SMA-M)

and BeCuB Gold Plated (SMA-F)

Connectors

Model

Conn1

Conn2

SMA-Male

SMA-Female Bulkhead

086-7SBSM+
