ADRF6510
Data Sheet
Rev. B | Page 14 of 32
INPUT SIGNAL = 45mV p-p
OUTPUT SIGNAL = 450mV p-p
20dB OF GAIN
VGAIN = 800mV TO 1.40V
400ns/DIV
30MHz BANDWIDTH,
28MHz MAINTONE
VGAIN = 1400mV
TO 800mV
28MHz SIGNAL = 45mV p-p
TO 450mV p-p
Figure 41. Gain Step Response
