background image
DS-TRAP-7
Page 3
1.
Open the enclosure by removing fixing screws from the enclosure
2.
Remove the antenna and slide out the circuit board.
3.
Connect the power supply screw terminals 12-32V ac or dc to the supply terminals.
4.
Wire your desired connections to the relay switches
5.
Once all required wiring is complete, use the handheld QUANTA transmitter to switch the outputs on and
off.
6.
As supplied, the handheld will operate the outputs - button 1 to output 1, button 2 to output 2 etc.
7.
Change the output functions to latching, / Momentary Operation.
Relay Connections when
Transmitter NOT Operating
Relay Connections when
Transmitter OPERATING
Relay
Relay
Relay
12V
0V
COM
NO
NC
Supply
Terminals
TRAP-RX
