AD8260
Data Sheet
Rev. B | Page 28 of 32
POWER SUPPLY
+5 V
-5 V
HIGH
CURRENT
DRIVER
OUTPUT
FUNCTION
GENERATOR FOR VGA
INPUT
HIGH
CURRENT
DRIVER
INPUTS
VGA
OUTPUT
(TO SCOPE)
SINGLE-
ENDED
VGA INPUT
RLOAD
PULSE GENERATOR WITH
DIFFERENTIAL OUTPUT
Figure 69. Typical Evaluation Board Connections
