PHOENIX CONTACT Deutschland GmbH

Page 1 / 6

http://www.phoenixcontact.de

Aug 19, 2011

Extract from the online

catalog

PLC-RSC- 24UC/21-21

Order No.: 2967073

The illustration shows the version PLC-RSC- 24DC/21-21

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2967073

PLC relay, consisting of base terminal block PLC-BSC.../21 with screw

connection and pluggable miniature relay with power contact, for

assembly on DIN rail NS 35/7.5, 2 PDT, input voltage 24 V AC/DC

Commercial data

GTIN (EAN)

4

017918

156381

sales group

G230

Pack

10 pcs.

Customs tariff

85364190

Catalog page information

Page 83 (IF-2011)

Product notes

WEEE/RoHS-compliant since:

02/09/2006

http://

www.download.phoenixcontact.com

Please note that the data given

here has been taken from the

online catalog. For comprehensive

information and data, please refer

to the user documentation. The

General Terms and Conditions of

Use apply to Internet downloads.

Technical data

Coil side

Nominal input voltage UN

24 V AC/DC

Nominal input current at UIN

17.5 mA (at UN = 24 V AC)

17.5 mA (at UN = 24 V DC)
