Data Sheet

SSM2212

Rev. C | Page 5 of 12

ABSOLUTE MAXIMUM RATING

Table 3.

Parameter

Rating

Breakdown Voltage of

40 V

Breakdown Voltage of

40 V

Breakdown Voltage of

40 V

Breakdown Voltage of

40 V

20 mA

20 mA

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Resistance

Package Type

Unit

8-Lead SOIC (R-8)

120

45

°C/W

16-Lead LFCSP (CP-16-22)

75

4.4

°C/W

ESD CAUTION
