SSM2518

Datasheet

Rev. B | Page 8 of 48

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings apply at 25°C, unless otherwise noted.

Table 6.

Parameter

Rating

PVDD Supply Voltage

−0.3 V to +6 V

DVDD Supply Voltage

−0.3 V to +3.6 V

Input Voltage (ADDR, MCLK, BCLK, LRCLK,

SDATA, SAMOD Pins)

−0.3 V to +3.6 V

Input Voltage (SD, SDA, and SCL Pins)

−0.3 V to +6 V

ESD Susceptibility

4 kV

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 7. Thermal Resistance

Package Type

θJA

Unit

16-ball, 2 mm × 2 mm WLCSP

°C/W

20-lead, 4.0 mm × 4.0 mm LFCSP

°C/W

ESD CAUTION
