Part

Material

Simplex plug housing

Synthetic resin

Spring

Stainless Steel

Ferrule

Zirconia

Simplex adapter housing

Synthetic resin or Zinc alloy

4-position adapter housing

Synthetic resin

5-position adapter housing

Synthetic resin

Receptacle housing

Zinc alloy

Attenuator housing

Zinc alloy

Split sleeve

Zirconia or copper alloy

Dust cap

Synthetic resin

sProduct Specifications

Ratings

Operating temperature range

-25°C to +70°C

(SM)

(GI)

Storage temperature range

-25°C to +70°C

sMaterials

Item

Test Method (IEC 61300)

Specifications

Insertion Loss

Wavelength 1310nm (LD)

0.5dB max. (PC, AdPC, APC)

Wavelength 1310nm (LED)

0.3dB max. (PC)

Return Loss

Wavelength 1310nm (LD)

Engagement and Separation

/force

Ferrule withdrawal force

Extract zirconia gauge 2.499 ±0.0005 mm dia

Copper alloy split sleeve

2N to 5.9N

from split sleeve.

Zirconia split sleeve

2N to 3.9N

Cable retention

89N tensile load for one minute.

1) Insertion loss fluctuation after test: 0.2dB max.

(Straight pull)

2) No visible damage, dislocation of clamp or cable.

Durability

1000 times

(cycles, mating/un-mating)

Vibration

Shock

Humidity

-10°C to 65°C, humidity: 90% to 96%

(Temperature/ humidity- cycles)

20 cycles

Change of temperature

-40°C to +75°C 42 cycles

(Complies with Telcordia standard GR-326-CORE)

Dry heat

960 hours at 85°C

Cold

960 hours at -25°C

Salt mist

48 hours in a 5% concentration of salt mist

No significant corrosion.

Measured with corresponding connector.

Frequency: 10 to 55 Hz, single amplitude of 0.75 mm,

2 hours in each of the 3 axis.

Acceleration of 981 m/s2, 6 ms duration,

sin half-wave waveform, 10 cycles in each of the 3 axis.

Simplex plug

Engagement force: 19.6 N max.

Separation force: 19.6 N max.

Duplex plug

Engagement force: 39 N max.

Separation force: 39 N max.

1) Insertion loss fluctuation after test: 0.2dB max.

2) No visible damage, cracks or part dislocation.

(SM)

(GI)

22dB min. (PC)

40dB min. (AdPC)

60dB min. (APC)

22dB min. (PC)
