38
sTools
CL No.
704-0287-0
Part Number
HSC-T3
Applicable connector
SC plug for 2mm, 3mm cable.
qCrimp Tool
(This is used in crimping of Kevlar at time of the plug termination.)
(1)2mm Jacket crimping: Please select section A
3mm Jacket crimping: Please select section C
(2)KevlarTM crimping: Please select section B
1.Open the tip of tool by compressing levers as shown below.
<How to operate>
Hold/release lever
qHSC2 Insertion/Extraction Tool
CL No.
704-0286-8
Part Number
HSC-T1-L
Applicable Products
HSC2 series.
qPlug assemble Tool
CL No.
Part Number
902-6029-1
HSC2-PH2/CVMD
<Locations>
2.Insert the tool (with opening the tips) into adapter.
3.Release the levers (then the tool catch HSC2 plug) and you can release the connector.
