LXXLD37
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
6 of 7
www.unisonic.com.tw
QW-R102-091.b
TYPICAL APPLICATION CIRCUIT
Using an Output Capacitor with ESR ≥ 18mΩ
×
O
R1
V= 0.8 (
)
R2
Using an MLCC as the Output Capacitor
UTC
LXXLD37
POK
EN
Enable
POK
EN
GND
FB
VOUT
VOUT
VIN
VCNTL
R3=1kΩ
R2=2kΩ
R1=kΩ
COUT=22µF
VIN +1.5V
CCNTL=1µF
CIN=22µF
Option
VCNTL +5V
×
O
R1
V= 0.8 (1+
)
R2
