background image
SSM3515
Data Sheet
Rev. A| Page 8 of 41
ABSOLUTE MAXIMUM RATINGS
Absolute maximum ratings apply at TA = 25°C, unless otherwise
noted.
Table 7.
Parameter
Rating
PVDD Supply Voltage
−0.3 V to +18 V
VREG18/DVDD Supply Voltage
−0.3 V to +1.98 V
VREG50/AVDD Supply Voltage
−0.3 V to +5.5 V
PGND and AGND Differential
±0.3 V
ADDR, SDATA Input Voltage
−0.3 V to +1.98 V
SCL, SDA, BCLK, FSYNC Input Voltage
−0.3 V to +5.5 V
REG_EN Input Voltage
−0.3 V to +18 V
Storage Temperature Range
−65°C to +150°C
Operating Temperature Range
−40°C to +85°C
Junction Temperature Range
−65°C to +165°C
Lead Temperature Range
(Soldering, 60 sec)
300°C
Stresses at or above those listed under Absolute Maximum
Ratings may cause permanent damage to the product. This is a
stress rating only; functional operation of the product at these
or any other conditions above those indicated in the operational
section of this specification is not implied. Operation beyond
the maximum operating conditions for extended periods may
affect product reliability.
THERMAL RESISTANCE
θJA (junction to air) is specified for worst case conditions, that is,
a device soldered in a circuit board for surface-mount packages. θJA
and θJB are determined according to JESD51-9 on a 4-layer
printed circuit board (PCB) with natural convection cooling.
Table 8. Thermal Resistance
Package Type
θJA
Unit
20-Ball, 1.8 mm × 2.2 mm WLCSP
55.5
°C/W
ESD CAUTION
