FEATURES

Popular series for rough service

Stud cathode and stud anode version

RoHS compliant

TYPICAL APPLICATIONS

SEMICONDUCTOR

RoHS

Fast Recovery Diodes

Nell High Power Products

Designed and qualified for industrial level

150FD(R)Series

Stud Version, 150A

Welders

Power supplies

Motor controls

Battery chargers

PRODUCT SUMMARY

IF(AV)

150A

MAJOR RATINGS AND CHARACTERISTICS

PARAMETER

UNIT

nS

trr

IFSM

IF(AV)

2

I t

TJ

kA²s

A

ºC

TEST CONDITIONS

Maximum TC

ºC

A

3000

3141

45

40.9

-40 to 175

50 HZ

60 HZ

50 HZ

60 HZ

Tj = 25°C

ELECTRICAL SPECIFICATIONS

VOLTAGE RATINGS

VOLTAGE

TYPE

NUMBER

CODE

V

, MAXIMUM

RRM

REPETITIVE PEAK

REVERSE VOLTAGE

V

, MAXIMUM

RSM

NON-REPETITIVE

PEAK REVERSE VOLTAGE

V

l

, MAXIMUM

RRM

AT T = 175 °C

J

mA

150FD( R )

04

06

08

10

12

400

600

800

1000

1200

500

700

900

1100

1300

15

Alloy diode

General industrial current rectification

125

250 to 500

DO-205AA(DO-8)

150FD(R)

150

Ceramic housing

Freewheeling diodes

High power drives

Glass passivated chip

V

VRRM

Range

400 to 1200

Fast recovery rectifier applications

Reverse recovery time ( ) < 500 nS

trr

High voltage ratings up to 1200V

( Metric stud )

Page 1 of 6

www.nellsemi.com
