Technical Data 10427

Effective August 2015

FP1110V

High frequency, high current power inductors

Description

•

Vertical design utilizes less board space

•

Controlled DCR for sensing circuits

•

Inductance Range from 195 nH to 320nH

•

Current range from 42 to 70 amps

•

10.7 x 7.5mm and 10.5 x 6.2mm footprint

surface mount package in a 9.5mm height

•

Ferrite core material

•

Halogen free, lead free, RoHS compliant

Applications

•

Servers

•

Multi-phase and Vcore regulators

•

Voltage Regulator Modules (VRMs)

•

Desktop VRMs and EVRDs

•

Data networking and storage systems

•

Point-of-Load modules

•

DCR Sensing circuits

Environmental Data

•

Storage temperature range (Component):

-40°C to +125°C

•

Operating temperature range: -40°C to +125°C

(ambient + self-temperature rise)

•

Solder reflow temperature: J-STD-020D

compliant

Pb

HALOGEN

HF

FREE
