PRODUCT FAMILY DATA SHEET

C4SMM-RJY/GJY/BJY

Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice.

Cree, the Cree logo and XLamp are registered trademarks of Cree, Inc.

PRODUCT DESCRIPTION

These oval LEDs are designed for full

color video displays and signs for live

action events and advertising signs.

The oval-shaped radiation pattern

and high luminous intensity ensure

that these devices are excellent for

wide-field-of -view outdoor applica-

tions where a wide viewing angle and

readability in sunlight are essential.

These lamps are made with an ad-

vanced optical-grade epoxy that offers

superior high-temperature and high-

moisture-resistance performance in

outdoor signal and sign applications.

The encapsulation resin contains anti-

UV material in order to reduce the ef-

fects of long-term exposure to direct

sunlight.

FEATURES

•

Size (mm): 4

•

Color and Typical Dominant

Wavelength:

Red (621nm)

Green(527nm)

Blue(472nm)

•

Luminous Intensity (mcd)

C4SMM-RJY: (715-1415)@15mA

C4SMM-GJY: (1205-2347)@10mA

C4SMM-BJY: (240-470)@10mA

•

Lead - Free

•

RoHS Compliant

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

www.cree.com/xlamp

Copyright © 2019 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and

the Cree logo are registered trademarks of Cree, Inc.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

APPLICATIONS

•

Electronic Signs & Signals

(ESS)

•

Full Color video screen

•

Motorway Signs

•

Variable Message Sign (VMS)

•

Advertising signs

•

Petrol Signs
