Environmental Specifications

Description

Specification

Temperature Operating Range

-55 to +125 deg C

.

Process Specifications

Process

Specification

Cable Preconditioning

5 cycles, -55 °C to +125°C, 20 minute dwells

Soldering

in accordance with J-STD-001, class 3

Marking

shall meet the adherence requirements of SAEAS5942

Workmanship

shall be in accordance with IPC/WHMA-A-620, class 3

.

Tests and Inspections

Description

Sampling

Connector Gaging (pin and insulator position)

100%

Insertion Loss

100%

VSWR

100%

Dielectric Withstanding Voltage (DWV)

100%

Visual - workmanship, configuration and marking

100%

Length

C=0, 1.5AQL

Mass

C=0, 1.5AQL

.

Plotted and Other Data

Notes:

• Values at 25°C, sea level.

PE3M0168 REV 1.2

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: Temperature Conditioned TNC Female Bulkhead to N Female Bulkhead Low Loss Cable Us-

ing PE-P142LL Coax PE3M0168

RF Cable Assemblies Technical Data Sheet

Temperature Conditioned TNC Female Bulkhead to N Female

Bulkhead Low Loss Cable Using PE-P142LL Coax

PE3M0168
