Pasternack does not make

any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

4

Environmental Specifications

Description

Specification

Temperature Operating Range

-55 to +125 deg C

.

Process Specifications

Process

Specification

Cable Preconditioning

5 cycles, -55 °C to +125°C, 20 minute dwells

Soldering

in accordance with J-STD-001, class 3

Marking

shall meet the adherence requirements of SAEAS5942

Workmanship

shall be in accordance with IPC/WHMA-A-620, class 3

.

Tests and Inspections

Description

Sampling

Connector Gaging (pin and insulator position)

100%

Insertion Loss

100%

VSWR

100%

Dielectric Withstanding Voltage (DWV)

100%

Visual - workmanship, configuration and marking

100%

Length

C=0, 1.5AQL

Mass

C=0, 1.5AQL

.

Plotted and Other Data

Notes:

• Values at 25°C, sea level.

PE3M0177 REV 1.2

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: Temperature Conditioned N Female Bulkhead to N Female Bulkhead Low Loss Cable Using

PE-P142LL Coax PE3M0177

RF Cable Assemblies Technical Data Sheet

Temperature Conditioned N Female Bulkhead to N Female

Bulkhead Low Loss Cable Using PE-P142LL Coax

PE3M0177
