MLG20N-2080P10501 | MLG-2 ProNet

MEASURING AUTOMATION LIGHT GRIDS

Power consumption receiver

141 mA 2)

Ripple

< 5 Vpp

Output current Imax.

100 mA

Output load capacitive

100 nF

Output load inductive

1 H

Initialization time

< 1 s

Dimensions (W x H x D)

34 mm x 2,173.3 mm x 30.6 mm

Housing material

Aluminum

Indication

LED

Enclosure rating

IP65, IP67

Circuit protection

UV connections, reverse polarity protected, Output Q short-circuit protected, Interference pulse

suppression

Protection class

III

Weight

4.447 kg

Front screen

PMMA

Option

Nonexistent

1) Without load.

2) , Without load with 24 V.

3) Operating in outdoor condition only with a external protection housing.

Performance

Maximum range

7 m 1)

Minimum range

≥ 0 m

Operating range

5 m

Response time

9.4 ms 2) 3)

1) No reserve for environmental issue and deterioration of the diode.

2) Without high speed.

3) With resistive load.

Interfaces

Interface

PROFIBUS DP

Ambient data

EMC

EN 60947-5-2

Ambient operating temperature

–30 °C +55 °C

Ambient storage temperature

–40 °C +70 °C

Ambient light immunity

Direct: 150,000 lx 1)

Indirect: 200,000 lx 2)

Vibration resistance

Sinusoidal oscillation 10-150 Hz 5 g

Shock load

Continuous shocks 10 g, 16 ms, 1000 shocks

Single shocks 15 g, 11 ms 3 per axle

UL File No.

NRKH.E181493 (Sensor)

NRAQ.E238799 (Fieldbus module)

1) Outdoor mode.

2) Light resistance indirect.

2019-07-19 17:41:20 | Online data sheet

Subject to change without notice

AUTOMATION LIGHT GRIDS | SICK
