background image
SE2529L
RangeCharger™ 2.4GHz Power Amplifier
63-DST-01 Rev 2.0 Nov 9/03
4 of 10
Absolute Maximum Ratings
These are stress ratings only. Exposure to stresses beyond these maximum ratings may cause permanent damage
to, or affect the reliability of the device. Avoid operating the device outside the recommended operating conditions
defined below. This device is ESD sensitive. Handling and assembly of this device should be at ESD protected
workstations.
Symbol
Definition
Min.
Max.
Unit
VCC
Supply Voltage on VCC0, VCC1, VCC2 and OUT/VCC3
-0.3
+3.6
V
Vbb
Bias Voltage (Vb1, Vb2, Vb3)
-0.3
+3.6
V
IN
RF Input Power
+8
dBm
TA
Operating Temperature Range
-40
+85
°C
TSTG
Storage Temperature Range
-40
+150
°C
Tj
Maximum Junction Temperature
+150
°C
Recommended Operating Conditions
Symbol
Parameter
Min.
Max.
Unit
VCC
Supply Voltage (VCC0, VCC1, VCC2, OUT/VCC3)
3.0
3.6
V
TA
Ambient Temperature
-40
85
°C
DC Electrical Characteristics
802.11g DC Electrical Characteristics
Conditions: VCC = 3.3V, Vbb = 2.9V TA = 25°C, as measured on SiGe Semiconductors SE2529L-EV1 evaluation
board, unless otherwise noted. “802.11g” mode, circuit tuning/biasing optimized for “g” full rate signal.
Symbol
Parameter
Note
Min.
Typ.
Max.
Unit
ICC
Supply Current (POUT = 19 dBm, 54 Mbps
OFDM signal, 64QAM)
1
175
200
225
mA
∆IccTEMP
Supply Current variation over temperature
from TA = 25°C (-40°C < TA < +85°C)
1
±10
%
Notes: (1) ICC refers to the total current into VCC0, VCC1, VCC2 and OUT/Vcc3
802.11b DC Electrical Characteristics
Conditions: VCC = 3.3V, Vbb = 2.9V, TA = 25°C, as measured on SiGe Semiconductors SE2529L-EV1 evaluation
board, unless otherwise noted. “802.11b” mode, circuit tuning/biasing optimized for “g” full rate signal.
Symbol
Parameter
Note
Min.
Typ.
Max.
Unit
ICC
Supply Current (POUT = 23dBm, 11Mbps
CCK signal)
1
240
280
305
mA
∆IccTEMP
Supply Current variation over temperature
from TA = 25°C (-40°C < TA < +85°C)
1
±10
%
Notes: (1) ICC refers to the total current into VCC0, VCC1, VCC2 and OUT/Vcc3
