Table 1-2 Absolute Maximum Ratings at Ts=25°C

Notes

1. 1/10 Duty cycle, 0.1ms pulse width.

2. The above forward voltage measurement allowance tolerance is ±0.1V.

3. The above dominant wavelength measurement allowance tolerance is ±2nm.

4. The above luminous intensity measurement allowance tolerance ±10%.

5. Care is to be taken that power dissipation does not exceed the absolute maximum rating of the product.

6. All measurements were made under the standardized environment of Refond.

7.When the LEDs are in operation the maximum current should be decided after measuring the package

temperature, junction temperature should not exceed the maximum rate

Parameter

Symbol

Rating

Units

Power Dissipation

72

mW

Forward Current

30

mA

Peak Forward Current Of Pulse

60

mA

Electrostatic Discharge

(HBM)

2000

V

Operating Temperature

-40 ~ +85

℃

Storage Temperature

-40 ~ +85

℃

Junction Temperature

95

℃
