1 / 3 page

NE8FDP-R

Right angle RJ45 feedthrough receptacle, D-shape metal ﬂange

with latch lock, mounting screws included

The etherCON Series is a ruggedized and lockable RJ45

connector system, optimized for pro audio, video and lightning

network applications. The chassis connectors are shaped to ﬁt

into standardized panels out of the entertainment industry.

The D-Series oﬀers the most rugged design of the etherCON

series and is perfectly suitable for panel mount and the installer

market.

Attention! Does not intermate with CAT6 cable connector

NE8MC6-MO and NKE6S* cables.

Features & Beneﬁts

Right angle CAT5e jack for space saving connections

on the rear

•

Accommodates NE8MC* or any standard RJ45 plugs

•

Approved latch lock system

•

Mountable from the front or rear of the panel

•

Complies with CAT5e according to TIA / EIA 568B and

ISO / IEC 11801 standards

•

NE8FDP-R

1

/3
