background image
Product data sheet
Characteristics
QO2175SB
Surge Breaker - QO - 22.5kA -120/240VAC -
1P3W - T2
Product availability : Stock - Normally stocked in distribution facility
Price** : 159.00 USD
Main
Product
Secondary surge arrester
Range
Surge Breaker
QO
Complementary
Surge Current
22.5 kA
Voltage Rating
120/240 V AC
Number of Phases
1 phase
Wiring Configuration
3-wire
MCOV
150 V
300 V
SCCR
22 kA
Local Signalling
1 LED green normal operation
Product destination
Load center QO
Height
3.7 in (93.98 mm)
Width
1.5 in (38.10 mm)
Depth
2.6 in (66.04 mm)
Environment
Enclosure Rating
NEMA 2
Ambient Operating
149 °F (65 °C)
Ordering and shipping details
Category
08461 - SURGE PROTECTION RESI
Discount Schedule
DE1B
GTIN
00785901210894
Apr 7, 2020
1
