03.10.2012   Page 1 / 7

Base strip - MSTBV 2,5/11-G - 1753615

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in

the user's documentation. Our General Terms of Use for Downloads are valid

(http://download.phoenixcontact.com)

Header, Nominal current: 12 A, Rated voltage (III/2): 320 V, Number of positions: 11, Pitch: 5 mm,

Color: green, Contact surface: Tin, Assembly: Soldering

The figure shows a 10-position

version of the product

Why buy this product

 Versions with and without side panel

 Other pin lengths available on request

 Plug-in direction parallel and vertical to the PCB

 Standard pin strip for 320 V (III/2)



Key commercial data

Packing unit

1

Minimum order quantity

1

Catalog page

Page 289 (CC-2011)

GTIN

Custom tariff number

85366990

Country of origin

GERMANY

Technical data

Dimensions / positions

Length

8.6 mm

Pitch

5 mm

Dimension a

50 mm

Number of positions

11

Pin dimensions

1 x 1 mm

Hole diameter

1.4 mm

Technical data

Range of articles

MSTBV 2,5/..-G

Insulating material group

IIIa

Rated surge voltage (III/3)

4 kV
