PHOENIX CONTACT Deutschland GmbH

Page 1 / 5

http://www.phoenixcontact.de

Feb 24, 2010

Extract from the online

catalog



MSTBV 2,5/12-G

Order No.: 1753631

The figure shows a 10-position version of the product

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1753631





Header, Nominal current: 12 A, Nom. voltage: 250 V, Pitch: 5 mm,

Number of positions: 12, Color: green, Assembly: Soldering



Commercial data

EAN

4017918028473

Pack

50 pcs.

Customs tariff

85366990

Weight/Piece

0.00505 KG

Catalog page information

Page 251 (CC-2009)

Product notes

WEEE/RoHS-compliant since:

01/01/2003

http://

www.download.phoenixcontact.com

Please note that the data given

here has been taken from the

online catalog. For comprehensive

information and data, please refer

to the user documentation. The

General Terms and Conditions of

Use apply to Internet downloads.

Technical data

Dimensions / positions

Length

8.6 mm

Pitch

5 mm

Dimension a

55 mm

Number of positions

12

Pin dimensions

1 x 1 mm
