DOCUMENT : CYNP-199-025

Page : 3

REVISION

: A0

Current Sensor Resistor

Type Designation :

S C M M

1206

S

D

ー

□ □ □ □

□

(1)

(2)

(3)

(4)

(5)

(6)

P/N list :

P/N

R value

TCR

Power Rating

Tolerance

(mΩ)

(ppm/K)

(W)

1%

2%

5%

SCMM1206SD-R001*

1.0

±75

0.5



SCMM1206SD-1M50*

1.5

±75

0.5



SCMM1206SD-R002*

2.0

±75

0.5



SCMM1206SD-R003*

3.0

±75

0.5



SCMM1206SD-R004*

4.0

±75

0.5



SCMM1206SD-R005*

5.0

±75

0.5



SCMM1206SD-R006*

6.0

±75

0.5



SCMM1206SD-R007*

7.0

±75

0.5



SCMM1206SD-R008*

8.0

±75

0.5



SCMM1206SD-R009*

9.0

±75

0.5



SCMM1206SD-R010*

10.0

±75

0.5



* Note : Other values and tolerance would be available, please contact Cyntec.

Note :

(1) Series No.

(2) Size

(3) Terminal Type : S = Short terminal

(4) Power Rating : D = 0.5W

(5) Resistance value : R003 = 0.003, R010 = 0.01

(6) Tolerance : F = ±1%, G = ±2%, J = ±5%
