MODEL: M2MNV

M2MNV SPECIFICATIONS

ES-5095 Rev.9 Page 5/6

http://www.m-system.co.jp/

SWITCHING OPERATIONS

1

2

4

5

7

8

1

2

4

5

7

8

Current Signal (no receiving resistor)

Power : OFF

Switching command : OFF (open)

1

2

4

5

7

8

1

2

4

5

7

8

Power : ON

Switching command : OFF (open)

1

2

4

5

7

8

1

2

4

5

7

8

Power : ON

Switching command : ON (short)

Current Signal (receiving resistor 50 Ω)

Voltage Signal

Current Signal (no receiving resistor)

Transition (ON to OFF, OFF to ON) Status

Power : ON

Switching command : OFF to ON

or

Power : ON

Switching command : ON to OFF

Current Signal (receiving resistor 50 Ω)

Voltage Signal

*1. Resistor is provided only for the input code 2: Current signal (receiving resistor 50 Ω).

*1. Resistor is provided only for the input code 2: Current signal (receiving resistor 50 Ω).

*1

*1

*1

*1

1

2

4

5

7

8

1

2

4

5

7

8

*1

*1

*1

*1

• Switching Status

When the switching command contact is switched from

OFF to ON or from ON to OFF, the signal channel is

switched only after all photo MOSFET relays turn on

(closed).

When the switching command contact is switched from

OFF to ON or from ON to OFF, the signal channel is

switched only after all photo MOSFET relays turn off

(open).

Single contact is used to switch from Signal Channel 1 (A1 – B1) to Signal Channel 2 (A2 – B1) and vice versa.

CHANNEL 1 (A1)

CHANNEL 2 (A2)

Terminal 3 – 9 OFF (open)

OFF

ON

Terminal 3 – 9 ON (closed)

ON

OFF

Status LED turn on when the respective channels are alive.

Double contacts are used to independently switch Signal Channel 1 (A1 – B1) and Signal Channel 2 (A2 – B1).

CHANNEL 1 (A1)

CHANNEL 2 (A2)

Terminal 3 – 9 OFF (open)

OFF

----

Terminal 3 – 9 ON (closed)

ON

----

Terminal 6 – 9 OFF (open)

----

OFF

Terminal 6 – 9 ON (closed)

----

ON

Status LED turn on when the respective channels are alive.
