MODEL: RZMS-U9

RZMS-U9 SPECIFICATIONS

ES-7605 Rev.13 Page 5/12

http://www.m-system.co.jp/

RTD Input, Celsius

RTD

USABLE RANGE (°C)

ACCURACY

at < 0°C

at ≥ 0°C

Pt 100 (JIS ’97, IEC)

-200 to +850

±0.4°C

±[0.4°C + Measured Value × 0.1%]

(±1.3°C at 850°C)

Pt 200

-200 to +850

±0.3°C

±[0.3°C + Measured Value × 0.17%]

(±1.8°C at 850°C)

Pt 300

-200 to +850

±[0.4°C + Measured Value × 0.08%]

(±0.24°C at -200°C)

±[0.4°C + Measured Value × 0.21%]

(±2.2°C at 850°C)

Pt 400

-200 to +850

±[0.4°C + Measured Value × 0.11%]

(±0.18°C at -200°C)

±[0.4°C + Measured Value × 0.21%]

(±2.2°C at 850°C)

Pt 500

-200 to +850

±[0.4°C + Measured Value × 0.13%]

(±0.14°C at -200°C)

±[0.4°C + Measured Value × 0.26%]

(±2.6°C at 850°C)

Pt 1000

-200 to +850

±[0.4°C + Measured Value × 0.15%]

(±0.10°C at -200°C)

±[0.4°C + Measured Value × 0.4%]

(±3.8°C at 850°C)

Pt 100 (JIS ’89)

-200 to +660

±0.4°C

±[0.4°C + Measured Value × 0.1%]

(±1.1°C at 650°C)

JPt 100 (JIS ’89)

-200 to +510

±0.4°C

±[0.4°C + Measured Value × 0.1%]

(±0.91°C at 510°C)

Pt 50Ω (JIS ’81)

-200 to +649

±0.5°C at < 160°C, ±[0.4°C + Measured Value × 0.1%] at ≥ 160°C (±1.049°C at 649°C)

Ni 100

-80 to +260

±0.3°C

Ni 120

-80 to +260

±0.3°C

Ni 508.4Ω

-50 to +280

±[0.25°C + Measured Value × 0.06%] (±0.22°C at -50°C, ±0.42°C at 280°C)

Ni-Fe 604

-200 to +200

±0.9°C at -200°C, ±0.6°C at -150°C, ±0.5°C at ±100°C, ±0.7°C at 200°C

Cu 10 @ 25°C

-50 to +250

±1.2°C (only after the field calibrations)

RTD Input, Fahrenheit

RTD

USABLE RANGE (°F)

ACCURACY

at < 32°F

at ≥ 32°F

Pt 100 (JIS ’97, IEC)

-328 to +1562

±0.72°F

±[0.4°C + Measured Value × 0.1%]

(±1.3°C at 850°C)

Pt 200

-328 to +1562

±0.54°F

±[0.3°C + Measured Value × 0.17%]

(±1.8°C at 850°C)

Pt 300

-328 to +1562

±[0.72°F + Measured Value × 0.08%]

(±0.44°F at -328°F)

±[0.4°C + Measured Value × 0.21%]

(±2.2°C at 850°C)

Pt 400

-328 to +1562

±[0.72°F + Measured Value × 0.11%]

(±0.33°F at -328°F)

±[0.4°C + Measured Value × 0.21%]

(±2.2°C at 850°C)

Pt 500

-328 to +1562

±[0.72°F + Measured Value × 0.13%]

(±0.26°F at -328°F)

±[0.4°C + Measured Value × 0.26%]

(±2.6°C at 850°C)

Pt 1000

-328 to +1562

±[0.72°F + Measured Value × 0.15%]

(±0.18°F at -328°F)

±[0.4°C + Measured Value × 0.4%]

(±3.8°C at 850°C)

Pt 100 (JIS ’89)

-328 to +1220

±0.72°F

±[0.4°C + Measured Value × 0.1%]

(±1.1°C at 650°C)

JPt 100 (JIS ’89)

-328 to +950

±0.72°F

±[0.4°C + Measured Value × 0.1%]

(±0.91°C at 510°C)

Pt 50Ω (JIS ’81)

-328 to +1200

±0.9°F at < 320°F, ±[0.72°F + Measured Value × 0.1%] at ≥ 320°F (±1.888°F at 1200°F)

Ni 100

-112 to +500

±0.54°F

Ni 120

-112 to +500

±0.54°F

Ni 508.4Ω

-58 to +536

±[0.45°F + Measured Value × 0.06%] (±0.40°F at -58°F, ±0.76°F at 536°F)

Ni-Fe 604

-328 to +392

±1.62°F at -328°F, ±1.08°F at -238°F, ±0.9°F at ±212°F, ±1.26°F at 392°F

Cu 10 @ 25°C

-58 to +482

±2.16°F (only after the field calibrations)

Note 1: The lower the temperature range, the better the accuracy is for Pt 300, Pt 400, Pt 500, Pt 1000 and Ni 508.4Ω.

‘Measured Value’ in the equations is not an absolute value. Include the minus sign when calculating accuracies.

Note 2: For Cu 10 @ 25°C, be sure to perform the field calibrations of wire imbalance and zero/span by using the PC Configurator

Software.
