PLL601-12

Dual Output PLL Clock with Selectable Odd Multiplier

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 3

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other con-

ditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. Crystal Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Resonator Frequency

Parallel Fundamental Mode

(see Selection Table)

13

31

MHz

Crystal Loading Rating

At VCON = 1.65V

16

pF

Recommended ESR

AT cut

30

Ω

3. General Electrical Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Fout<30MHz

15

30MHz<Fout<100MHz

30

Supply Current, Dynamic

(with Loaded Outputs)

15 pF

load

Fout >100MHz

40

mA

Operating Voltage

2.97

3.63

V

Short Circuit Current

±50

mA

4. AC Electrical Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

0.8V ~ 2.0V with 10 pF load

1.5

Output Clock Rise Time

0.3V ~ 3.0V with 15 pF load

3.7

5

2.0V ~ 0.8V with 10 pF load

1.5

Output Clock Fall Time

3.0V ~ 0.3V with 15pF load

3.7

5

ns

Output Clock Duty Cycle

Measured @ 1.4V

45

50

55

%
