PLL701-25

Low EMI Spread Spectrum Multiplier Clock

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com

Rev 10/04/05 Page 3

3. Timing Characteristics

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Input Frequency

33

90

MHz

Rise Time

Measured at 0.8V ~ 2.0V @ 3.3V

0.8

0.95

1.1

ns

Fall Time

Measured at 2.0V ~ 0.8V @ 3.3V

0.78

0.85

0.9

ns

Output Duty Cycle

45

50

55

%

Input to Output Delay

2

4

ns

Cycle to Cycle Jitter

Over output frequency range @ 3.3V

100

ps
