PLL602-20

200MHz XO IC With Selectable 4X/8X Multiplier

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 02/18/05 Page 3

ELECTRICAL SPECIFICATIONS

ABSOLUTE MAXIMUM RATINGS

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage Range

4.6

V

Input Voltage Range

V

Output Voltage Range

V

Soldering Temperature (Green package)

260

°C

Storage Temperature

-65

150

°C

Ambient Operating Temperature

0

70

°C

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

AC SPECIFICATIONS

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Input Frequency(XIN)

Fundamental Crystal

10

30

MHz

Settling Time

At power-up (after VDD increases over

1.62V)

10

ms

Output Rise Time

15pF Load, 10/90%VDD

1.2

2.0

ns

Output Fall Time

15pF Load, 90/10%VDD

1.2

2.0

ns

Duty Cycle

At VDD/2

45

50

55

%

Period Jitter, peak-to-peak*

(measured from 10,000

samples)

With capacitive decoupling between VDD

and GND. Operating only one output.

70

ps
