SOFTWARE

SOFTWARE

Product

Features

Accessory For

Solutions-M

Relay Interface

Software

Provides the ability to configure and monitor Modbus

networks. The features include data logging, real-time data

monitoring and fault and event monitoring. Devices can be

added and configured manually or the software can scan

an existing network to identify devices which can be used

as is or reconfigured by the user. Setpoints for each device

can be uploaded and downloaded for easy monitoring and

reconfiguration.

RS485

TCP/IP networks

MotorSaver and

PumpSaver Devices

SE-COMM-RIS

Relay Interface

Software

Provides remote access to metering, control, data logging, and

programming features. Setpoints can be accessed individually,

downloaded as a file, and protective curves can be plotted.

Metered data can be observed or logged for later study.

MPU-32

MPS

FPU-32

FPS

SE-FLASH

Firmware

Update Utility

Used to update relay firmware to add new features.

MPU-32

MPS

FPU-32

FPS

EL731

SE-MON330

Relay Interface Software

Used to receive data from the SE-330. It displays relay set

points and measured values, and features data logging of

information at a selectable interval.

SE-330

SE-330HV

SE-330AU

PGW-6150

Relay Interface Software

Provides access to the settings, measurements, configurations,

and reports recorded in the relay. Allows changes to operation

parameters and to work offline, and creating a library of

settings for future applications.

PGR-6150

PGW-8800

Relay Interface Software

Provides access to basic and advanced settings over a USB

connection. No installation required.

PGR-8800

VMPU

Virtual Motor

Protection Relay

Allows the user to scroll through the MPU-32 Motor Protection

Relay menu.

MPU-32

VMPS

Virtual Motor

Protection System

Allows the user to scroll through the MPS Motor Protection

System menu.

MPS

VFPU

Virtual Feeder

Protection Relay

Allows the user to scroll through the FPU-32 Feeder Protection

Relay menu.

FPU-32

MPU-32 Tutorial

MPU-32 Online

Self-Training Tutorial

Online Self-Training tutorial for MPU-32 programming.

MPU-32

Protection Relays and Alarm Systems are supplied with free software.The software simplifies programming and allows the user to

save setpoint files and reuse them for similar applications.

The software gives the ability to change parameters and see the impact on the protection time current curves. It also allows another

device curve to be entered to view simple coordination.
