background image
Data Sheet
ADP1850
Rev. C | Page 5 of 32
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
Rating
VIN, EN1/EN2, RAMP1/RAMP2
21 V
FB1/FB2, COMP1/COMP2, SS1/SS2, TRK1/TRK2,
FREQ, SYNC, VCCO, VDL, PGOOD1/PGOOD2
−0.3 V to +6 V
ILIM1/ILIM2, SW1/SW2 to PGND1/PGND2
−0.3 V to +21 V
BST1/BST2, DH1/DH2 to PGND1/PGND2
−0.3 V to +28 V
DL1/DL2 to PGND1/PGND2
−0.3V to VCCO + 0.3 V
BST1/BST2 to SW1/SW2
−0.3 V to +6 V
BST1/BST2 to PGND1/PGND2
20 ns Transients
32 V
SW1/SW2 to PGND1/PGND2
20 ns Transients
25 V
DL1/DL2, SW1/SW2, ILIM1/ILIM2 to
PGND1/PGND2
20 ns Negative Transients
−8 V
PGND1/PGND2 to AGND
−0.3 V to +0.3 V
PGND1/PGND2 to AGND 20 ns Transients
−8 V to +4 V
θJA on Multilayer PCB (Natural Convection)1,2
32.6°C/W
Operating Junction Temperature Range3
−40°C to +125°C
Storage Temperature Range
−65°C to +150°C
Maximum Soldering Lead Temperature
260°C
1 Measured with exposed pad attached to PCB.
2 Junction-to-ambient thermal resistance (θ
JA) of the package was calculated
or simulated on multilayer PCB.
3 The junction temperature, T
J, of the device is dependent on the ambient
temperature, TA, the power dissipation of the device, PD, and the junction-to-
ambient thermal resistance of the package, θJA. Maximum junction
temperature is calculated from the ambient temperature and power
dissipation using the formula: TJ = TA + PD × θJA.
Stresses at or above those listed under Absolute Maximum
Ratings may cause permanent damage to the product. This is a
stress rating only; functional operation of the product at these
or any other conditions above those indicated in the operational
section of this specification is not implied. Operation beyond
the maximum operating conditions for extended periods may
affect product reliability.
Absolute maximum ratings apply individually only, not in
combination. Unless otherwise specified, all other voltages are
referenced to GND.
ESD CAUTION
