Description

Features

n WIDEVOLTAGERANGES–

2.4TO110VOLTS

Mechanical Dimensions

n 5 & 10% VOLTAGE TOLERANCES AVAILABLE

n MEETS UL SPECIFICATION 94V-0

Maximum Ratings

DC Power Dissipation with T

Derate Above 50°C

Operating & Storage Temperature Range...T

SOT Z Series

Data Sheet

2.4V to 110V MLL

ZENER DIODES (1/2 Watt)

Units

mW

mW / °C

°C

............................................ 500 ..............................................

............................................ 3.3 ..............................................

......................................... -65 to 200 ..........................................

Page 10-50

ZENER VOLTAGE VS. CURRENT 4.7V TO 47V

Dimensions in inches

and (millimeters)

Steady State Power Derating

1V Bias

Temp. Coefficients vs. Voltage

Typical Junction Capacitance

Zener Voltage

Reverse Voltage (Volts)

0V Bias

50% CH Vz Bias
