CD08CM0S-K-R datasheet(4/4 Pages) CK-COMPONENTS

4 / 4 page

Dimensions are shown inch (mm)

Dimensions subject to change

www.ittcannon.com

H-25

C&K CD Series

8mm DIP Coded Rotary Switches

TERMINATIONS

C PC THRU-HOLE

A RIGHT ANGLE, PC THRU-HOLE

S SURFACE MOUNT

.200

(5,08)

.100 TYP.

(2,54)

Ø.032

(0,81)

TYP.

.050.

(1,27)

.200

(5,08)

.100

(2,54)

.020 TYP.

(0,51)

.010

(0,25)

.183

(4,64)

TYP.

.025

(0,64)

.025

(0,64)

.132

(3,34)

.025 TYP.

(0,64)

STAND-OFF

.315

(8,00)

.330

(8,36)

.315

(8,00)

.099

(2,52)

.200

(5,08)

.200

(5,08)

.100

(2,54)

.010 TYP.

(0,25)

.168

(4,27)

.025 TYP.

(0,64)

.025 TYP.

(0,64)

.125 TYP.

(3,18)

.305

(7,75)

.315

(8,00)

.315

(8,00)

.100 TYP.

(2,54)

.100

(2,54)

.032 TYP.

(0,81)

.020 TYP.

(0,51)

.300

(7,62)

F 1

.020 TYP.

(0,51)

.010 THK.

(0,25)

.040 TYP.

(1,02)

.315

(8,00)

.315

(8,00)

.200

(5,08)

.390

(9,90)

.174

(4,41)

.006

(0,15)

.100

(2,54)

.200

(5,08)

.100 TYP.

(2,54)

.080

(2,03)

.050

(1,27)

TYP.

.430

(10,92)

CONTACT MATERIAL

OPTION

CONTACT

TERMINAL

RATING

CODE

MATERIAL

PLATING

K (STD.)

GOLD

TIN-LEAD

LOW LEVEL/DRY CIRCUIT

0.4 VC MAX. @ 20 V AC or DC MAX.

TAPE & REEL

For part number CDxxMOSK

Reel Information

Outside diameter

13.00 (333,0)

Pilot hole

.512 (13,0)

Third Angle

Projection
