3 / 14 page

Pin description and connection diagram

Figure 2. Pin connection (top view)

13 14

24 23

30 29 28 27 26 25

GND

SENSE

OUT

EP1

EP2

EP3

SENSE

OUTb

BOOT

PGND

PVCC

2.1

Pin list

Table 1. Pin description

Pin Number

Pin Name

Type

Function

15, 16, 17, 18, 19

Power Supply

High voltage supply (high-side GaN Drain)

12, 13, 14, EP3

OUT

Power Output

Half-bridge output

4, 5, 6, 7, 8, 9, 10, 11, EP2 SENSE

Power Supply

Half-bridge sense (low-side GaN Source)

BOOT

Power Supply

Gate driver high-side supply voltage

OUTb

Power Supply

Gate driver high-side supply voltage, used only for Bootstrap

capacitor connection. Internally connected to OUT.

VCC

Power Supply

Logic supply voltage

PVCC

Power Supply

Gate driver low-side supply voltage

MASTERGAN4

Pin description and connection diagram

DB4419 - Rev 1

page 3/14
