Data Sheet

ADP5587

Rev. E | Page 5 of 24

ABSOLUTE MAXIMUM RATINGS

Table 6.

Parameter

Rating

VCC

−0.3 V to + 4.0 V

R0 to R7, C0 to C9

−0.3 V to VCC + 0.3 V

SCL

−0.3 V to VCC + 0.3 V

SDA

−0.3 V to VCC + 0.3 V

RST

−0.3 V to VCC + 0.3 V

INT

−0.3 V to VCC + 0.3 V

GND

−0.3 V to +0.3 V

Operating Ambient Temperature Range

−40°C to +85°C

Operating Junction Temperature Range

−40°C to +125°C

Storage Temperature Range

−65°C to +150°C

ESD Machine Model

±200 V

ESD Human Body Model

±2000 V

ESD Charged Device Model

±1000 V

Soldering Condition

JEDEC J-STD-020

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 7. Thermal Resistance

Package Type

θJA

θJC

Unit

24-Lead LFCSP_WQ

57.8

9.4

°C/W

Maximum Power

600

N/A

25-Ball WLCSP

N/A

°C/W

Maximum Power

600

N/A

ESD CAUTION
