1 / 1 page  MCU and SoC Products Overview Apollo Apollo2 Apollo4 Apollo2 Blue Apollo3 Blue Apollo3 Blue Plus Apollo4 Blue MCU Frequency 24 MHz 48 MHz 96 MHz 192 MHz TurboSPOT 48 MHz 48 MHz 96 MHz TurboSPOT 48 MHz 96 MHz TurboSPOT 96 MHz 192 MHz TurboSPOT MCU 32-bit Arm Cortex-M4F 32-bit Arm Cortex-M4F 32-bit Arm Cortex-M4F, DMA 32-bit Arm Cortex-M4F Dedicated BLE Core 32-bit Arm Cortex-M4F, DMA, Arm Cortex-M0 for BLE 32-bit Arm Cortex-M4F, DMA Arm Cortex-M0 for BLE 32-bit Arm Cortex-M4F, DMA, Arm Cortex-M0 for BLE MCU Power Efficiency 34 µA/MHz 10 µA/MHz < 3 µA Deep Sleep Mode < 3 μA/MHz 10 µA/MHz < 3 µA Deep Sleep Mode < 6 μA/MHz < 1 μA Deep Sleep Mode < 6 μA/MHz < 1 μA Deep Sleep Mode < 3 μA/MHz NVM 512KB Flash 1MB Flash 2MB MRAM 1MB Flash 1MB Flash 2MB Flash 2MB MRAM SRAM 64KB 256KB 1.8MB 256KB 384KB 768KB 1.8MB Voltage 2.2-3.8 V 1.755-3.63 V 1.71-2.2 V 1.755-3.63 V 1.755-3.63 V 1.755-3.63 V 1.71-2.2 V ADC 10-bit, 13-channel, up to 800 kSps Sampling Rate ADC 14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC 12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC 14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC 14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC 14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC 12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC UART 1 2 4 2 2 2 4 I/O I2C/SPI master (2x) I2C/SPI slave I2C/SPI master (6x) I2C/SPI slave I2C/SPI master (8x) I2C/SPI slave USB FS/HS SDIO v3.0/1x eMMC I2C/SPI master (4x) I2C/SPI slave I2C/SPI master (6x) I2C/SPI slave I2C/SPI master (6x) I2C/SPI slave I2C/SPI master (7x) I2C/SPI slave USB FS/HS SDIO v3.0/1x eMMC MSPI - - Dual/Quad/Octal-SPI Master (3x) 96 MHz SDR 48 MHz DDR - Dual/Quad/Octal-SPI Master 48 MHz SDR ISO7816 Master Dual/Quad/Octal-SPI Master (3x) 48 MHz SDR ISO7816 Master Dual/Quad/Octal-SPI Master (3x) 96 MHz SDR 48 MHz DDR I2S - I2S slave for PDM Audio Pass-through I2S master/slave (2x) full-duplex with ASRC I2S slave for PDM Audio Pass-through I2S slave for PDM Audio Pass-through I2S slave for PDM Audio Pass-through I2S master/slave (2x) full-duplex with ASRC Audio - Dual Interface PDM for Mono and Stereo Audio Microphones 4x Stereo Digital Microphones 2x LP Analog Microphone with PGA Dual Interface PDM for Mono and Stereo Audio Microphones Dual Interface PDM for Mono and Stereo Audio Microphones Dual Interface PDM for Mono and Stereo Audio Microphones 4x Stereo Digital Microphones 2x LP Analog Microphone with PGA Display - - SPI 3-wire/4-wire Dual/QuadSPIMIPI DSI x2 4-layer Display Controller - SPI 3-wire/4-wire SPI 3-wire/4-wire Dual/QuadSPI SPI 3-wire/4-wire Dual/QuadSPI MIPI DSI x2 4-layer Display Controller Graphics - - 2D/2.5D GPU - - - 2D/2.5D GPU Security - - SecureSPOT 2.0 AES 128-bit Encryption SecureSPOT SecureSPOT SecureSPOT 2.0 Connectivity - - - BLE 5 BLE 5 BLE 5 BLE 5 RF Sensitivity - - - -95 dBm -94 dBm -94 dBm -97 dBm Rx Current - - - 3.5 mA 3 mA 3 mA 3 mA Tx Current - - - 5 mA @ 0 dBm 3 mA @ 0 dBm 3 mA @ 0 dBm 3 mA @ 0 dBm Tx Output Power - - -20 dBm to +6.8 dBm -40 dBm to +5 dBm -20 dBm to +4 dBm -20 dBm to +4 dBm -20 dBm to +6.8 dBm Packages • 4.5 mm x 4.5 mm, 64-pin BGA with 50 GPIO • 2.49 mm x 2.90 mm, 41-pin WLCSP with 27 GPIO • 4.5 mm x 4.5 mm, 64-pin BGA with 50 GPIO • 2.5 mm x 2.5 mm, 49-pin WLCSP with 34 GPIO • 2.5 mm x 2.5 mm, 49-pin WLCSP with 300um with backside coating (Thin) • 5 mm x 5 mm, 146-pin BGA with 105 GPIO • 3.9 mm x 3.9 mm, 121-pin WLCSP with 82 GPIO 4 mm x 4 mm x 0.9mm, 64-pin LGA with up to 31 GPIO • 4.5 mm x 4.5 mm, 81-pin BGA with 50 GPIO • 3.25 mm x 3.37 mm, 66-pin WLCSP with 37 GPIO • 3.25 mm x 3.37 mm, 66-pin WLCSP 300um with backside coating (Thin) 5.3 mm x 5.3 mm x 0.8 mm, 108-pin BGA with 74 GPIO 4.7 mm x 4.7 mm, 131-pin SiP BGA with 81 GPIO Ordering Information • APOLLO512-KBR ( BGA) • APOLLO512-KCR ( WLCSP) • AMAP1EVB (EVB) • AMAPH1KK-KBR (BGA) • AMAPH1KK-KCR (WLCSP) • AMAPH1KK-KCR- TB (Thin) • AMAPHEVB (EVB) • AMAP42KK-KBR (BGA) • AMAP42KK-KCR (WLCSP) • AMA2B1KK-KLR • AMA2BEVB (EVB) • AMA3B1KK-KBR- B0 (BGA) • AMA3B1KK-KCR- B0 (WLCSP) • AMAP31KK-KCR (WLCSP, non-BLE) • AMA3B1KK-KCR- TB (Thin) • AMA3BEVB (EVB) • AMA3B2KK-KBR • AMA3B2EVB (EVB) AMA4B2KK-KBR |
