FT800 Embedded Video Engine Datasheet
Version 1.4
Document No.: BRT_000039 Clearance No.: BRT#001
Pin No.
Name
Type
Description
Pad powered from pin VCC.
20
Y+
AI/O
Connect to Y top electrode of 4-wire touch-screen
panel.
Pad powered from pin VCC.
21
X-
AI/O
Connect to X left electrode of 4-wire touch-
screen panel.
Pad powered from pin VCC.
22
Y-
AI/O
Connect to Y bottom electrode of 4-wire touch-
screen panel.
Pad powered from pin VCC.
23
GND
P
Ground
24
BACKLIGHT
O
LED Backlight brightness PWM controls signal,
push-pull output, 4/8mA sink/source current.
Pad powered from pin VCC.
25
DE
O
LCD Data Enable, push-pull output, 4/8mA
sink/source current.
Pad powered from pin VCC.
26
VSYNC
O
LCD Vertical Sync, push-pull output, 4/8mA
sink/source current.
Pad powered from pin VCC.
27
HSYNC
O
LCD Horizontal Sync, push-pull output, 4/8mA
sink/source current.
Pad powered from pin VCC.
28
DISP
O
General purpose output pin for LCD Display
Enable, push-pull output, 4/8mA sink/source
current. Control by writing to Bit 7 of REG_GPIO
register.
Pad powered from pin VCC.
29
PCLK
O
LCD Pixel Clock, push-pull output, 4/8mA
sink/source current.
Pad powered from pin VCC.
30
B7
O
Bit 7 of Blue RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
31
B6
O
Bit 6 of Blue RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
32
B5
O
Bit 5 of Blue RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
33
B4
O
Bit 4 of Blue RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
34
B3
O
Bit 3 of Blue RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
35
B2
O
Bit 2 of Blue RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
36
GND
P
Ground
37
G7
O
Bit 7 of Green RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
38
G6
O
Bit 6 of Green RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
39
G5
O
Bit 5 of Green RGB signals, push-pull output,
4/8mA sink/source current.
Pad powered from pin VCC.
40
G4
O
Bit 4 of Green RGB signals, push-pull output,
