9SQL4952/9SQL4954/9SQL4958 Datasheet
BCLK2
Output
True output of differential BCLK.
23
22
—
BCLK2#
Output
Complement output of differential BCLK.
24
23
—
BCLK3
Output
True output of differential BCLK.
26
27
—
BCLK3#
Output
Complement output of differential BCLK.
27
28
—
BCLK4
Output
True output of differential BCLK.
32
—
—
BCLK4#
Output
Complement output of differential BCLK.
33
—
—
BCLK5
Output
True output of differential BCLK.
35
—
—
BCLK5#
Output
Complement output of differential BCLK.
36
—
—
BCLK6
Output
True output of differential BCLK.
41
—
—
BCLK6#
Output
Complement output of differential BCLK.
42
—
—
BCLK7
Output
True output of differential BCLK.
44
—
—
BCLK7#
Output
Complement output of differential BCLK.
45
—
—
EPAD
GND
Connect to ground.
49
33
25
GND
GND
Ground pin.
22
15
10
GND
GND
Ground pin.
40
26, 30
21
GNDA
GND
Ground pin for the PLL core.
29
20
15
GNDDIG
GND
Ground pin for digital circuitry.
9
8
6
GNDREF
GND
Ground pin for the REF outputs.
8
7
5
GNDXTAL
GND
GND for XTAL.
2
1
24
SCLK_3.3
Input
Clock pin of SMBus circuitry, 3.3V tolerant.
10
10
8
SDATA_3.3
I/O
Data pin for SMBus circuitry, 3.3V tolerant.
11
11
9
VDD3.3
Power
Power supply, nominally 3.3V.
20
16
11
VDD3.3
Power
Power supply, nominally 3.3V.
38
25
20
VDDA3.3
Power
3.3V power for the PLL core.
30
21
16
VDDDIG3.3
Power
3.3V digital power (dirty power).
12
9
7
VDDIO
Power
Power supply for differential outputs.
13
—
—
VDDIO
Power
Power supply for differential outputs.
21
—
—
VDDIO
Power
Power supply for differential outputs.
31
—
—
VDDIO
Power
Power supply for differential outputs.
39
—
—
VDDIO
Power
Power supply for differential outputs.
47
—
—
VDDREF3.3
Power
Power supply for REF output, nominally 3.3V.
6
5
—
VDDXTAL3.3
Power
Power supply for XTAL, nominally 3.3V.
5
4
3
vOE0#
Input
Active low input for enabling output 0. This pin has an internal pull-down.
1 = disable output, 0 = enable output.
14
12
12
Table 1. Pin Descriptions (Cont.)
Name
Type
Description
9SQL4958
Pin No.
9SQL4954
Pin No.
9SQL4952
Pin No.
