P9235A-R Datasheet

© 2016 Integrated Device Technology, Inc

4

May 17, 2016

Table 5. Device Characteristic (Continued)

VIN = 5 V, VDDIO = 3.3 V, EN

¯¯ = 0V, LP = 6.5 µH, CP = 400 nF TA = -40C to +85C. Typical values are at 25°C, unless otherwise noted.

Symbol

Description

Conditions/Notes

Min

Typical

Max

Units

Clock Oscillators

FLSOSC

Low speed clock

50

kHz

FCLOCK

OSC clock frequency

6

MHz

FCENTER2

PLL VCO frequency

120

MHz

General Purpose Inputs/Outputs (GPIO)

VIH

Input high voltage

0.7*VDDIO

V

VIL

Input low voltage

0.3*VDDIO

V

ILKG

Leakage Current

-1.0

1 .0

µA

VOH

Output logic high

I=8mA

2.4

V

VOL

Output logic low

I=8mA

0.5

V

SCL, SDA (I2C Interface)

fSCL_MSTR

Clock Frequency

As I2C master

400

kHz

fSCL_SLV

Clock Frequency

As I2C slave

400

kHz

CB

Capacitive load

For each bus line

100

pF

CBIN

SCL, SDA Input Capacitance

5.0

pF

ILKG

Leakage Current

1.0

1.0

µA

NOTES:

1. Do not externally load. For internal biasing only.

2. Guaranteed by design and not subject to 100% production testing
