21 / 24 page  Preliminary Technical Data ADL5350 PrC | Page 21 of 24 70 MHz RECEIVE PERFORMANCE VS = 3 V, TA = 25°C, LO power = 4 dBm, re: 50 Ω, unless otherwise noted. Table 10. Parameter Unit RF Frequency 60 MHz LO Frequency 59.3 MHz IF Frequency 10.7 MHz Conversion Loss 6.7 dB SSB Noise Figure 6.7 dB Input Third-Order Intercept 27.3 dBm Supply Voltage 3 V Supply Current 18 mA Table 11 shows the spur performance for RF = 70 MHz and LO = 59.3 MHz; RFin = −5 dBm, Loin=4 dBm; all values in dBc referenced to RFin. Note that higher order spurious components falling in-band do become an issue as the bandwidth of the desired signal increases. Therefore, while operation at IF frequencies as low as 10 MHz is possible, the bandwidth of this signal needs to be taken into consideration. . Table 11. N × fRF − M × fLO-Mixer Spurious Products M 0.0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0 11.0 12.0 13.0 14.0 15.0 0.0 −6.8 −30.5 −23.3 −30.5 −28.9 −34.9 −41.1 −45.7 −37.8 −39.7 −42.3 −37.5 −48.8 −40.1 −39.1 −37.4 1.0 −15.3 −6.8 −18.1 −37.3 −19.8 −22.6 −41.5 −24.2 −26.9 −42.4 −27.7 −30.1 −43.4 −30.2 −32.9 −44.3 2.0 −51.5 −66.0 −57.8 −57.4 −63.1 −57.8 −55.6 −59.2 −56.3 −55.7 −61.3 −57.1 −55.7 −58.3 −56.8 −57.6 3.0 −71.4 −78.8 −73.1 −75.1 −80.6 −81.8 −78.3 −78.2 −72.3 −82.3 −77.7 −82.4 −76.3 −73.3 −74.3 −79.2 4.0 −82.9 −78.6 −81.0 −84.2 −79.7 −77.5 −76.6 −79.0 −74.9 −75.0 −75.8 −76.3 −89.2 −76.7 −87.9 −76.1 5.0 −76.2 −82.9 −78.6 −75.4 −78.7 −84.9 −77.6 −79.2 −84.5 −85.0 −75.9 −81.3 −74.9 −98.6 −73.6 −90.4 6.0 −88.6 −74.6 −79.1 −80.2 −77.1 −76.1 −85.8 −76.2 −81.2 −82.9 −89.7 −75.4 −82.9 −85.4 −78.1 −75.9 N 7.0 −90.6 −76.7 −79.9 −80.6 −81.0 −83.4 −73.1 −76.8 −77.9 −84.6 −80.0 −78.4 −73.2 −75.2 −79.3 −90.9 8.0 −81.8 −80.4 −84.6 −84.9 −79.5 −83.1 −80.1 −78.6 −89.9 −78.7 −75.3 −77.0 −81.6 −86.3 −85.0 −77.1 9.0 −90.2 −78.3 −80.2 −71.9 −73.9 −85.8 −82.2 −86.6 −80.2 −78.7 −79.1 −71.2 −78.8 −76.0 −84.5 −81.8 10.0 −78.2 −82.1 −80.3 −73.5 −86.6 −86.1 −81.0 −86.0 −78.2 −86.2 −87.1 −83.7 −79.8 −75.0 −83.8 −82.4 11.0 −77.6 −85.8 −78.4 −85.1 −86.6 −80.1 −79.4 −78.8 −69.3 −82.8 −81.6 −94.2 −81.7 −80.5 −84.1 −77.2 12.0 −89.4 −90.8 −80.8 −71.7 −73.4 −75.5 −82.2 −76.8 −72.1 −78.0 −76.3 −84.9 −85.6 −78.7 −71.8 −85.1 13.0 −80.0 −82.5 −79.6 −82.0 −78.9 −78.5 −73.4 −80.4 −84.9 −81.5 −79.4 −79.1 −76.1 −82.8 −77.8 −71.7 14.0 −86.3 −85.6 −89.2 −85.6 −82.7 −74.4 −88.1 −77.6 −74.4 −79.0 −85.4 −89.1 −88.4 −77.2 −81.1 −80.0 15.0 −84.4 −81.9 −81.1 −87.9 −77.7 −83.3 −78.4 −81.9 −90.0 −73.3 −84.6 −77.8 −81.7 −81.2 −93.2 −71.4 |
|
|
