Nexperia

BAS416

Low-leakage diode

6. Ordering information

Table 3. Ordering information

Package

Type number

Name

Description

Version

BAS416

SOD323

plastic, surface-mounted package; 2 leads; 1.3 mm pitch; 1.7

mm x 1.25 mm x 0.95 mm body

SOD323

7. Marking

Table 4. Marking codes

Type number

Marking code

BAS416

D4

8. Limiting values

Table 5. Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).

Symbol

Parameter

Conditions

Min

Max

Unit

VRRM

repetitive peak reverse

voltage

-

85

V

VR

reverse voltage

-

75

V

IF

forward current

Tj = 25 °C

-

200

mA

tp = 1 µs; square wave; Tj(init) = 25 °C

-

4

A

tp = 1 ms; square wave; Tj(init) = 25 °C

-

1

A

IFSM

non-repetitive peak

forward current

tp = 1 s; square wave; Tj(init) = 25 °C

-

0.5

A

IFRM

repetitive peak forward

current

-

500

mA

Ptot

total power dissipation

Tamb ≤ 25 °C

[1]

-

250

mW

Tj

junction temperature

-

150

°C

Tamb

ambient temperature

-55

150

°C

Tstg

storage temperature

-65

150

°C

[1] Device mounted on an FR4 Printed-Circuit Board (PCB), single-sided copper, tin-plated and standard footprint.
