BL1102series
http://www.belling.com.cn
- 6 -
8/22/2006
Total 9 Pages
Wrote by 2006
DC Characteristic
( VDD -VSS=2.5V，Fosc=3.58MHz，Ta=25
O
C,
all output unloaded except for being indicated.)
Parameter
Symbol
Test Condition
Min.
Typical
Max.
Unit
Operating voltage
VDD
tone
pulse
memory
2.0
2.0
1.0
5.5
5.5
5.5
V
Operating current
IOPT
IOPP
tone
pulse
0.6
0.2
2.0
0.5
mA
Memory retention
current
IMR
HKS＝1 , Ta=450OC
VDD = 1.0V
0.1
0.2
µA
Standby current
ISB
HKS＝0， N loaded
and N
0.1
5
µA
input
DTMF output voltage
Vto
Row group， RL=5K
Ω
130
150
170
mVrms
Pre-emphasis
Column/row group
VDD = 2.0 ~ 5.5V
1
2
3
dB
DTMF distortion
THd
RL=5K
Ω
-30
-23
dB
tone output outer
loading resistance
RL
TMD (-23dB)
5
K
Ω
tone output DC voltage
VDC
VDD = 2.5~5.5V
1.1
2.8
V
tone output sink current
ITC
VTO = 0.5V
0.2
mA
pulse output drive
current
IPC
VPO = 0.5V
0.5
mA
T/P mute output drive
IMH
VMO = 2.0V
-0.5
mA
/sink current
I ML
VMO = 0.5V
0.5
mute output drive / sink
IKH
VKO = 2.5V
-0.5
mA
current
I KL
VKO = 0.5v
0.5
XMT T/P mute
drive/sink
ILH
VLO = 2.0V
-0.5
mA
current
I LL
VLO = 0.5V
0.5
voltage input low level
VIL
GND
0.3VDD
V
voltage input high level
VI H
0.7VDD
VDD
key input drive/sink
IKD
VI= 0V
10
30
80
µA
current
I KS
VI= 0V
200
400
Pin control input
IIS
HKS，MODE ,M/B
±2.5
µA
