background image
Technical data
Product properties
Product type
Crimp contact
Product family
D3PC-MP-F
Pitch
0 mm
Connection data
Stripping length
4.5 mm
Conductor cross section AWG
24 ... 20
Material specifications
Contact surface
Tin Sn
Contact surface material
Tin
Metal surface terminal point (top layer)
Tin (1 - 3 µm Sn)
Metal surface contact area (top layer)
Tin (1 - 3 µm Sn)
Dimensions
Pitch
0 mm
Electrical properties
Nominal current IN
6 A
D3PC-MP 0,20-0,50-F-SN-R - Crimp contact
1340887
https://www.phoenixcontact.com/us/products/1340887
Jan 8, 2024, 6:04 AM
Page 2 (9)
