SPLS Series

Square pushbutton switch, 5 million cycles, optional LED

01

EXAMPLE : SPLSP-2-S2S-FC

Illuminated tact switch PCB type - Yellow cap - Super Yellow led-Flat cover

SPLS

00

FC

RC

RH

SC

SH

UT

DT

RT

LT

C4

C5

B4

Without Cover

Flat/clear

Round h=4.9mm/clear

Round h=6.9mm/clear

Square h=4.9mm/clear

Square h=6.9mm/clear

UP Triangle/clear

Down Triangle/clear

Right Triangle/clear

Left Triangle/clear

Flat cover/white

Flat cover/Foggy

Raised cover/white

B5 Raised cover/clear

Cover style / Color

"*" not standard type

please inquire first

LED Colors

01

S2S

03

S3

P3S

4S

7S

17

1P3

P37

Red

Super Yellow

Green

Super Green

Pure Green(single)

White (single)

Blue (single)

Red/Blue*

Red/Pure Green*

Pure Green/Blue*

Function Code

Illuminated

Switch

P

LED

Indicator

L

Cap Colors

1

2

3

4

5

6

7

Red

Yellow

Green

White

Transparent

Orange

Blue

A

B

Ice

Snow

General Specifications

Circuit

Current Rating

Contact Resistance

Insulation Resistance

Operating Force

Total Travel

Operating Life

Operating Temperature

Solder Specifications

Materials

Cover

Cap

Housing

Base

Lamp Term.

Act. Dome

End Term.

LED

:SPST

:50mA @ 12VDC

:100mOhm Max.(initial)

:100MOhm Min.

:300gf 50gf

:0.3mm 0.1mm

:5,000,000 cycles Min.

:-25 deg.~+60 deg.

:260 deg. for 3 seconds

:Polycarbonate (PC)

:Polycarbonate (PC)

:Polyamide (PA)

:Polyamide (PA)

:Phosphor bronze (PBS)

with gold plating

:Phosphor bronze (PBS)

with silver plating

:Brass with gold plating

:Surface Mount Chip LED

1

2

3

4

Cover

Cap

LED

Housing (Reflector)

Action dome

Base

Lamp terminal

End terminal

5.0

10.16

12.0

7.6

12.5

dia

. 1.

5

Single chip LED

Single Color / 2chips led

Dual Colors LED

1

3

4

2

(SPST)

Contact Configuration

SPLSP tact switch

Single Color LED

(-)

(+)

12.5

7.62

dia. 1.2-4

dia.

0.8

-2

dia. 1.8

Contact configuration

HOW TO ORDER
