Coil former

Material:

GFR thermosetting plastic (UL 94 V-0, insulation class to IEC 60085:

F

max. operating temperature 155 °C), color code green

Solderability: to IEC 60068-2-20, test Ta, method 1 (aging 3): 235 °C, 2 s

Resistance to soldering heat: to IEC 60068-2-20, test Tb, method 1B: 350 °C, 3,5 s

Winding:

see “Processing Notes”, page 156

Squared pins

Cap yoke

With ground terminal, made of stainless spring steel (tinned), 0,25 mm thick

Coil former

Cap yoke

Coil former

Ordering code

Sections

mm

µΩ

Terminals

1

4,7

17,7

128,7

4

6

B65840-B1004-D1

B65840-B1006-D1

2

4,2

17,7

143,8

4

6

B65840-B1004-D2

B65840-B1006-D2

Cap yoke

B65840-D2000

FEP0005-Z

View in mounting direction

Hole arrangement

4,8

ø1+0,2

Ground ø1,3+0,2

4,4 0,1

_

10,7

7 0,1

_

0,2

_

3,6+0,1

Marking

of pin 1

0,45

0,5±0,05

0,1

_

FEP0006-U

5,6

3,8

8,2 min.

9,6 min.

0,4

A

View A

6,6 min.

_

1 0,1

B65840

Accessories

EP 7
