background image
CLM2D-RCC/ACC: PLCC4 RED & AMBER SMD LEDs
© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered
trademarks of Cree LED.
CLD-CT1409
REV 6
3
INTENSITY BIN LIMIT
Red (20 mA)
Amber (20 mA)
Bin Code
Min.(mcd)
Max.(mcd)
Bin Code
Min.(mcd)
Max.(mcd)
Xa
1800
2240
Xa
1800
2240
Xb
2240
2800
Xb
2240
2800
Ya
2800
3550
Ya
2800
3550
Yb
3550
4500
Yb
3550
4500
Z0
4500
5600
Z0
4500
5600
*
Tolerance of measurement of luminous intensity is ±10%
COLOR BIN LIMIT
Red (20 mA)
Amber (20 mA)
Bin Code
Min.(nm)
Max.(nm)
Bin Code
Min.(nm)
Max.(nm)
RB
619
624
A2
584
587
A3
587
590
A4
590
593
A5
593
596
*
Tolerance of measurement of dominant wavelength is ±1 nm.
