TC7109/A

DS21456C-page 24

6.3

Package Dimensions

Dimensions: inches (mm)

2.065 (52.45)

2.027 (51.49)

.200 (5.08)

.140 (3.56)

.150 (3.81)

.115 (2.92)

.070 (1.78)

.045 (1.14)

.022 (0.56)

.015 (0.38)

.110 (2.79)

.090 (2.29)

.555 (14.10)

.530 (13.46)

.610 (15.49)

.590 (14.99)

.015 (0.38)

.008 (0.20)

.700 (17.78)

.610 (15.50)

.040 (1.02)

.020 (0.51)

40-Pin PDIP (Wide)

Pin1

3° Min.

Dimensions: inches (mm)

.015 (0.38)

.008 (0.20)

.620 (15.75)

.590 (15.00)

.700 (17.78)

.620 (15.75)

.540 (13.72)

.510 (12.95)

2.070 (52.58)

2.030 (51.56)

.210 (5.33)

.170 (4.32)

.020 (0.51)

.016 (0.41)

.110 (2.79)

.090 (2.29)

.065 (1.65)

.045 (1.14)

.200 (5.08)

.125 (3.18)

.098 (2.49) Max.

.030 (0.76) Min.

.060 (1.52)

.020 (0.51)

.150 (3.81)

MIN.

40-Pin CERDIP (Wide)

Pin 1

3° Min.
